DDA - Direct Drive Tube Axial Duct Fan CFM Range: 1,450-22,600 (12"-30" Dia.)


 E-mail this product to a friend



DDA - DIRECT DRIVE TUBE AXIAL DUCT FANS

      Minimum maintenance. Maximum efficiency.

FEATURES
  • Cast aluminum blades are standard.
  • TEFC motors are standard.

BLADE DIAMETER MODEL#

RPM

 H.P. dBA @ 5' CFM @ STATIC PRESSURE
SINGLE PHASE THREE PHASE 0" 1/4" 1/2" 3/4" 1" 1 1/4"
12" DDA12T10033B DDA12T30033B 1750 1/3 49 1450 1230 313 --- --- ---
DDA12T10100A DDA12T30100A 3450 1 72 2860 2740 2640 2530 2410 2140
15" DDA15T10033B DDA15T30033B 1750 1/3 65 2630 2320 1840 --- --- ---
18" DDA18T10033C DDA18T30033C 1140 1/3 49 2990 2450 845 --- --- ---
DDA18T10075B DDA18T30075B 1750 3/4 61 4590 4280 3910 3260 1750 ---
24" DDA24T10050C DDA24T30050C 1140 1/2 52 4990 4180 2920 1210 --- ---
DDA24T10100C DDA24T30100C 1140 1 57 6520 5630 4380 1920 813 ---
DDA24T10150C DDA24T30150C 1140 1.5 61 8710 7630 6020 2380 720 ---
DDA24T10150B DDA24T30150B 1750 1.5 65 7660 7160 6620 5980 5170 4020
DDA24T10200B DDA24T30200B 1750 2 66 9210 8660 8090 7470 6660 5540
DDA24T10300B DDA24T30300B 1750 3 71 11500 10900 10200 9490 8680 7540
30" DDA30T10100C DDA30T30100C 1140 1 57 8680 7480 6000 3630 1550 ---
DDA30T10150C DDA30T30150C 1140 1.5 61 11800 10600 8950 6070 3070 ---
--- DDA30T30200C 1140 2.0 62 12780 11490 9850 7320 3620 ---
--- DDA30T30300C 1140 3.0 68 16400 14700 12700 6840 4120 ---
DDA30T10300B DDA30T30300B 1750 3.0 69 13300 12550 11700 11000 9980 8830
DDA30T10500B DDA30T30500B 1750 5.0 73 18200 17350 16550 15200 14600 13880
DDA30T10750B DDA30T30750 1750 7.5 77 22600 21980 20650 19030 18300 17550



























Printable Manual (614 Kb)



   Related Information:
   Operation & Maintenance Manual (WallExhaustAX-P.pdf)








**Go to Bottom of This Page to See Available Options.
DDA12T10033B (12" Dia., 1/3 Hp, 1 Phase, 115V, 1450 CFM @ 0" S.P.)
SKU:DDA12T10033B
Weight:14.00
Price: $735.67

Quantity:
DDA12T30033B (12" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 1450 CFM @ 0" S.P.)
SKU:DDA12T30033B
Weight:14.00
Price: $710.76

Quantity:
DDA12T10100A (12" Dia., 1 Hp, 1 Phase, 115V, 2860 CFM @ 0" S.P.)
SKU:DDA12T10100A
Weight:14.00
Price: $816.77

Quantity:
DDA12T30100A (12" Dia., 1 Hp, 3 Phase, 208-230/460V, 2860 CFM @ 0" S.P.)
SKU:DDA12T30100A
Weight:14.00
Price: $754.19

Quantity:
DDA15T10033B (15" Dia., 1/3 Hp, 1 Phase, 115V, 2630 CFM @ 0" S.P.)
SKU:DDA15T10033B
Weight:42.00
Price: $745.25

Quantity:
DDA15T30033B (15" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2630 CFM @ 0" S.P.)
SKU:DDA15T30033B
Weight:14.00
Price: $720.34

Quantity:
DDA18T10033C (18" Dia., 1/3 Hp, 1 Phase, 115V, 2990 CFM @ 0" S.P.)
SKU:DDA18T10033C
Weight:55.00
Price: $1,018.57

Quantity:
DDA18T30033C (18" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2990 CFM @ 0" S.P.)
SKU:DDA18T30033C
Weight:55.00
Price: $922.78

Quantity:
DDA18T10075B (18" Dia., 3/4 Hp, 1 Phase, 115V, 4590 CFM @ 0" S.P.)
SKU:DDA18T10075B
Weight:55.00
Price: $855.72

Quantity:
DDA18T30075B (18" Dia., 3/4 Hp, 3 Phase, 208-230/460V, 4590 CFM @ 0" S.P.)
SKU:DDA18T30075B
Weight:55.00
Price: $781.01

Quantity:
DDA24T10050C (24" Dia., 1/2 Hp, 1 Phase, 115V, 4990 CFM @ 0" S.P.)
SKU:DDA24T10050C
Weight:55.00
Price: $1,376.82

Quantity:
DDA24T30050C (24" Dia., 1/2 Hp, 3 Phase, 208-230/460V, 4990 CFM @ 0" S.P.)
SKU:DDA24T30050C
Weight:102.00
Price: $1,137.35

Quantity:
DDA24T10100C (24" Dia., 1 Hp, 1 Phase, 115V, 6520 CFM @ 0" S.P.)
SKU:DDA24T10100C
Weight:102.00
Price: $1,550.52

Quantity:
DDA24T30100C (24" Dia., 1 Hp, 3 Phase, 208-230/460V, 6520 CFM @ 0" S.P.)
SKU:DDA24T30100C
Weight:102.00
Price: $1,215.26

Quantity:
DDA24T10150C (24" Dia., 1.5 Hp, 1 Phase, 115V, 8710 CFM @ 0" S.P.)
SKU:DDA24T10150C
Weight:102.00
Price: $1,509.16

Quantity:
DDA24T30150C (24" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 8710 CFM @ 0" S.P.)
SKU:DDA24T30150C
Weight:102.00
Price: $1,378.74

Quantity:
DDA24T10150B (24" Dia., 1.5 Hp, 1 Phase, 115V, 7660 CFM @ 0" S.P.)
SKU:DDA24T10150B
Weight:102.00
Price: $1,230.56

Quantity:
DDA24T30150B (24" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 7660 CFM @ 0" S.P.)
SKU:DDA24T30150B
Weight:102.00
Price: $1,141.37

Quantity:
DDA24T10200B (24" Dia., 2 Hp, 1 Phase, 115V, 9210 CFM @ 0" S.P.)
SKU:DDA24T10200B
Weight:102.00
Price: $1,598.35

Quantity:
DDA24T30200B (24" Dia., 2 Hp, 3 Phase, 208-230/460V, 9210 CFM @ 0" S.P.)
SKU:DDA24T30200B
Weight:102.00
Price: $1,240.51

Quantity:
DDA24T10300B (24" Dia., 3 Hp, 1 Phase, 115V, 11500 CFM @ 0" S.P.)
SKU:DDA24T10300B
Weight:102.00
Price: $1,553.37

Quantity:
DDA24T30300B (24" Dia., 3 Hp, 3 Phase, 208-230/460V, 11500 CFM @ 0" S.P.)
SKU:DDA24T30300B
Weight:102.00
Price: $1,302.31

Quantity:
DDA30T10100C (30" Dia., 1 Hp, 1 Phase, 115V, 8680 CFM @ 0" S.P.)
SKU:DDA30T10100C
Weight:102.00
Price: $1,591.99

Quantity:
DDA30T30100C (30" Dia., 1 Hp, 3 Phase, 208-230/460V, 8680 CFM @ 0" S.P.)
SKU:DDA30T30100C
Weight:102.00
Price: $1,254.67

Quantity:
DDA30T10150C (30" Dia., 1.5 Hp, 1 Phase, 115V, 11800 CFM @ 0" S.P.)
SKU:DDA30T10150C
Weight:102.00
Price: $1,789.35

Quantity:
DDA30T30150C (30" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 11800 CFM @ 0" S.P.)
SKU:DDA30T30150C
Weight:102.00
Price: $1,419.47

Quantity:
DDA30T30200C (30" Dia., 2 Hp, 3 Phase, 208-230/460V, 12780 CFM @ 0" S.P.)
SKU:DDA30T30200C
Weight:102.00
Price: $1,448.44

Quantity:
DDA30T30300C (30" Dia., 3 Hp, 3 Phase, 208-230/460V, 16400 CFM @ 0" S.P.)
SKU:DDA30T30300C
Weight:102.00
Price: $1,530.19

Quantity:
DDA30T10300B (30" Dia., 3 Hp, 1 Phase, 115V, 13300 CFM @ 0" S.P.)
SKU:DDA30T10300B
Weight:102.00
Price: $1,557.23

Quantity:
DDA30T30300B (30" Dia., 3 Hp, 3 Phase, 208-230/460V, 13300 CFM @ 0" S.P.)
SKU:DDA30T30300B
Weight:102.00
Price: $1,335.85

Quantity:
DDA30T10500B (30" Dia., 5 Hp, 1 Phase, 115V, 18200 CFM @ 0" S.P.)
SKU:DDA30T10500B
Weight:102.00
Price: $1,716.88

Quantity:
DDA30T30500B (30" Dia., 5 Hp, 3 Phase, 208-230/460V, 18200 CFM @ 0" S.P.)
SKU:DDA30T30500B
Weight:102.00
Price: $1,396.94

Quantity:
DDA30T10750B (30" Dia., 7.5 Hp, 1 Phase, 115V, 22600 CFM @ 0" S.P.)
SKU:DDA30T10500B
Weight:102.00
Price: $2,452.04

Quantity:
DDA30T30750B (30" Dia., 7.5 Hp, 3 Phase, 208-230/460V, 22600 CFM @ 0" S.P.)
SKU:DDA30T30750B
Weight:102.00
Price: $1,519.25

Quantity:


Tube Axial Duct Fan 4" Support Legs
Tube Axial Companion Ring
Tube Axial Duct Fan Guard
Tube Axial Inspection Door

Tube Axial Vertical and Horizontal Support Clips
