Canarm brand Direct Drive Tube Axial Duct Fan

BTA, WTA & HTA - Belt Drive Tube Axial Duct Fan CFM Range: 1,590-18,410 (12"-30" Dia.)

E-mail this product to a friend

BTA - For clean, dry air with a maximum temperature of 200ºF (95ºC).
• Adjustable motor base.
• Heavy duty pillow block ball bearings with high temperature grease.
• Extended lube lines with external grease fittings.
• TEFC motors are standard.
• Cast aluminum blades up to 48”; fans 54” & 60” have polypropylene reinforced fiberglass blades.
• Airfoil shaped belt tube for improved efficiency; motor, belts, drives and bearings are isolated from air stream.

WTA - For moisture laden air with a maximum temperature of 200ºF (95ºC).
• Heavy duty pillow block bearings with moisture displacement collars.

HTA - For clean, dry air with a maximum temperature of 375ºF (190ºC).

NOTE: To order WTA or HTA models, replace “BTA” with “WTA” or “HTA” in the table below.

BLADE DIAMETER	MODEL#		RPM	H.P.	dBA @ 5'	CFM @ STATIC PRESSURE
BLADE DIAMETER	SINGLE PHASE	THREE PHASE	RPM	H.P.	dBA @ 5'	0"	1/8"	1/4"	3/8"	1/2"	3/4"	1"	1 1/4"	1 1/2"
12"	BTA12T10033	BTA12T30033	2535	1/3	60	2100	2020	1950	1890	1800	---	---	---	---
	BTA12T10050	BTA12T30050	2865	3/4	64	2370	2330	2240	2190	2120	1940	1590	---	---
	BTA12T10075	BTA12T30075	3290	3/4 +	70	2720	2660	2610	2550	2500	2380	2200	1890	---
	BTA12T10100	BTA12T30100	3645	2 +	74	3020	2970	2910	2860	2810	2720	2600	2420	2150
15"	BTA15T10033	BTA15T30033	1850	1/3	61	2780	2640	2480	2290	2050	---	---	---	---
	BTA15T10050	BTA15T30050	2105	3/4	66	3170	3040	2910	2710	2580	2110	---	---	---
	BTA15T10075	BTA15T30075	2105	3/4	72	3620	3510	3410	3350	3150	2810	2380	---	---
	BTA15T10100	BTA15T30100	2660	1	75	4000	3910	3810	3690	3590	3320	2990	2570	1140
	BTA15T10150	BTA15T30150	3040	1.5 +	81	4580	4490	4390	4330	4220	3940	3780	3480	3150
18"	BTA18T10050	BTA18T30050	1556	3/4	58	4110	3930	3760	3540	3260	1760	---	---	---
	BTA18T10075	BTA18T30075	1785	3/4	61	4680	4530	4380	4210	4020	3440	1930	---	---
	BTA18T10100	BTA18T30100	1920	1	63	5040	4890	4750	4610	4440	4010	3290	1800	1210
	BTA18T10150	BTA18T30150	2255	1.5 +	68	5920	5790	5670	5550	5430	5140	4770	4210	3410
	BTA18T10200	BTA18T30200	2510	2.0	72	6590	6490	6360	6280	6150	5930	5650	5260	4790
24"	BTA24T10075	BTA24T30075	1180	3/4	58	6750	6325	5880	5360	4700	2180	---	---	---
	BTA24T10100	BTA24T30100	1295	1	61	7400	7020	6620	6180	5690	4690	1980	---	---
	BTA24T10150	BTA24T30150	1475	1.5	64	8430	8090	7680	7390	7000	6010	4320	3110	---
	BTA24T10200	BTA24T30200	1620	2.0	67	9260	8960	8640	8330	7990	7220	6190	6080	4130
	BTA24T10300	BTA24T30300	1890	3.0	72	10800	10670	10290	10060	9730	8890	8480	7640	6510
30"	BTA30T10100	BTA30T30100	965	1	58	10800	10050	9190	8100	6610	2620	---	---	---
	BTA30T10150	BTA30T30150	1095	1.5	61	12320	11650	11000	10130	9140	5210	2770	---	---
	BTA30T10200	BTA30T30200	1225	2.0	64	13810	13170	12550	11930	11100	9120	5260	5320	---
	BTA30T10300	BTA30T30300	1380	3.0	67	15490	14910	14540	13930	13270	11790	9830	10860	4130
	BTA30T10500	BTA30T30500	1635	5.0	73	18410	17850	17540	17160	16590	15470	14280	12820	10810

Printable Manual (614 Kb)

Related Information:
Operation & Maintenance Manual (WallExhaustAX-P.pdf)

*Please call for pricing to order HTA (High Temperature Models.)
**Go to Bottom of This Page to See Available Options.

BTA12T10033 (12" Dia., 1/3 Hp, 1 Phase, 115V, 2100 CFM @ 0" S.P.)

SKU:BTA12T10033

Weight:53.00

Price: $948.24

BTA12T30033 (12" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2100 CFM @ 0" S.P.)

SKU:BTA12T30033

Weight:53.00

Price: $922.49

WTA12T10033 for Moisture Laden Air (12" Dia., 1/3 Hp, 1 Phase, 115V, 2100 CFM @ 0" S.P.)

SKU:WTA12T10033

Weight:53.00

Price: $1,178.71

WTA12T30033 for Moisture Laden Air (12" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2100 CFM @ 0" S.P.)

SKU:WTA12T30033

Weight:53.00

Price: $1,152.31

BTA12T10050 (12" Dia., 3/4 Hp, 1 Phase, 115V, 2370 CFM @ 0" S.P.)

SKU:BTA12T10050

Weight:53.00

Price: $973.35

BTA12T30050 (12" Dia., 3/4 Hp, 3 Phase, 208-230/460V, 2370 CFM @ 0" S.P.)

SKU:BTA12T30050

Weight:53.00

Price: $931.51

WTA12T10050 for Moisture Laden Air (12" Dia., 3/4 Hp, 1 Phase, 115V, 2370 CFM @ 0" S.P.)

SKU:WTA12T10050

Weight:53.00

Price: $1,203.81

WTA12T30050 for Moisture Laden Air (12" Dia., 3/4 Hp, 3 Phase, 208-230/460V, 2370 CFM @ 0" S.P.)

SKU:WTA12T30050

Weight:53.00

Price: $1,161.97

BTA12T10075 (12" Dia., 3/4+ Hp, 1 Phase, 115V, 2720 CFM @ 0" S.P.)

SKU:BTA12T10075

Weight:53.00

Price: $987.51

BTA12T30075 (12" Dia., 3/4+ Hp, 3 Phase, 208-230/460V, 2720 CFM @ 0" S.P.)

SKU:BTA12T30075

Weight:53.00

Price: $945.67

WTA12T10075 for Moisture Laden Air (12" Dia., 3/4+ Hp, 1 Phase, 115V, 2720 CFM @ 0" S.P.)

SKU:WTA12T10075

Weight:53.00

Price: $1,217.98

WTA12T30075 for Moisture Laden Air (12" Dia., 3/4+ Hp, 3 Phase, 208-230/460V, 2720 CFM @ 0" S.P.)

SKU:WTA12T30075

Weight:53.00

Price: $1,176.13

BTA12T10100 (12" Dia., 2+ Hp, 1 Phase, 115V, 3020 CFM @ 0" S.P.)

SKU:BTA12T10100

Weight:53.00

Price: $1,019.06

BTA12T30100 (12" Dia., 2+ Hp, 3 Phase, 208-230/460V, 3020 CFM @ 0" S.P.)

SKU:BTA12T30100

Weight:53.00

Price: $955.33

WTA12T10100 for Moisture Laden Air (12" Dia., 2+ Hp, 1 Phase, 115V, 3020 CFM @ 0" S.P.)

SKU:WTA12T10100

Weight:53.00

Price: $1,249.52

WTA12T30100 for Moisture Laden Air (12" Dia., 2+ Hp, 3 Phase, 208-230/460V, 3020 CFM @ 0" S.P.)

SKU:WTA12T30100

Weight:53.00

Price: $1,185.79

BTA15T10333 (15" Dia., 1/3 Hp, 1 Phase, 115V, 2780 CFM @ 0" S.P.)

SKU:BTA15T10333

Weight:62.00

Price: $980.43

BTA15T30033 (15" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2780 CFM @ 0" S.P.)

SKU:BTA15T30033

Weight:62.00

Price: $955.33

WTA15T10033 for Moisture Laden Air (15" Dia., 1/3 Hp, 1 Phase, 115V, 2780 CFM @ 0" S.P.)

SKU:WTA15T10033

Weight:62.00

Price: $1,210.89

WTA15T30033 for Moisture Laden Air (12" Dia., 1/3 Hp, 3 Phase, 208-230/460V, 2780 CFM @ 0" S.P.)

SKU:WTA15T30033

Weight:62.00

Price: $1,185.79

BTA15T10050 (15" Dia., 1/2 Hp, 1 Phase, 115V, 3170 CFM @ 0" S.P.)

SKU:BTA15T10050

Weight:62.00

Price: $1,007.47

BTA15T30050 (15" Dia., 1/2 Hp, 3 Phase, 208-230/460V, 3170 CFM @ 0" S.P.)

SKU:BTA15T30050

Weight:62.00

Price: $964.34

WTA15T10050 for Moisture Laden Air (15" Dia., 1/2 Hp, 1 Phase, 115V, 3170 CFM @ 0" S.P.)

SKU:WTA15T10050

Weight:62.00

Price: $1,237.93

WTA15T30050 for Moisture Laden Air (15" Dia., 1/2 Hp, 3 Phase, 208-230/460V, 3170 CFM @ 0" S.P.)

SKU:WTA15T30050

Weight:62.00

Price: $1,194.16

BTA15T10075 (15" Dia., .8 Hp, 1 Phase, 115V, 3620 CFM @ 0" S.P.)

SKU:BTA15T10075

Weight:62.00

Price: $1,067.98

BTA15T30075 (15" Dia., .8 Hp, 3 Phase, 208-230/460V, 3620 CFM @ 0" S.P.)

SKU:BTA15T30075

Weight:62.00

Price: $988.80

WTA15T10075 for Moisture Laden Air (15" Dia., .8 Hp, 1 Phase, 115V, 3620 CFM @ 0" S.P.)

SKU:WTA15T10075

Weight:62.00

Price: $1,298.44

WTA15T30075 for Moisture Laden Air (15" Dia., .8 Hp, 3 Phase, 208-230/460V, 3620 CFM @ 0" S.P.)

SKU:WTA15T30075

Weight:62.00

Price: $1,219.26

BTA15T10100 (15" Dia., 1 Hp, 1 Phase, 115V, 4000 CFM @ 0" S.P.)

SKU:BTA15T10100

Weight:62.00

Price: $1,097.59

BTA15T30100 (15" Dia., 1 Hp, 3 Phase, 208-230/460V, 4000 CFM @ 0" S.P.)

SKU:BTA15T30100

Weight:62.00

Price: $1,010.04

WTA15T10100 for Moisture Laden Air (15" Dia., 1 Hp, 1 Phase, 115V, 4000 CFM @ 0" S.P.)

SKU:WTA15T10100

Weight:62.00

Price: $1,328.06

WTA15T30100 for Moisture Laden Air (15" Dia., 1 Hp, 3 Phase, 208-230/460V, 4000 CFM @ 0" S.P.)

SKU:WTA15T30100

Weight:62.00

Price: $1,240.51

BTA15T10150 (15" Dia., 1.5+ Hp, 1 Phase, 115V, 4580 CFM @ 0" S.P.)

SKU:BTA15T10150

Weight:62.00

Price: $1,188.36

BTA15T30150 (15" Dia., 1.5+ Hp, 3 Phase, 208-230/460V, 4580 CFM @ 0" S.P.)

SKU:BTA15T30150

Weight:62.00

Price: $1,127.21

WTA15T10150 for Moisture Laden Air (15" Dia., 1.5 Hp, 1 Phase, 115V, 4580 CFM @ 0" S.P.)

SKU:WTA15T10150

Weight:62.00

Price: $1,419.47

WTA15T30150 for Moisture Laden Air (15" Dia., 1.5+ Hp, 3 Phase, 208-230/460V, 4580 CFM @ 0" S.P.)

SKU:WTA15T30150

Weight:62.00

Price: $1,357.67

BTA18T10050 (18" Dia., 1/2 Hp, 1 Phase, 115V, 4110 CFM @ 0" S.P.)

SKU:BTA18T10050

Weight:76.00

Price: $1,070.56

BTA18T30050 (18" Dia., 1/2 Hp, 3 Phase, 208-230/460V, 4110 CFM @ 0" S.P.)

SKU:BTA18T30050

Weight:76.00

Price: $1,028.07

WTA18T10050 for Moisture Laden Air (18" Dia., 1/2 Hp, 1 Phase, 115V, 4110 CFM @ 0" S.P.)

SKU:WTA18T10050

Weight:76.00

Price: $1,301.02

WTA18T30050 for Moisture Laden Air (18" Dia., 1/2 Hp, 3 Phase, 208-230/460V, 4110 CFM @ 0" S.P.)

SKU:WTA18T30050

Weight:76.00

Price: $1,259.18

BTA18T10075 (18" Dia., 3/4 Hp, 1 Phase, 115V, 4680 CFM @ 0" S.P.)

SKU:BTA18T10075

Weight:76.00

Price: $1,121.41

BTA18T30075 (18" Dia., 3/4 Hp, 3 Phase, 208-230/460V, 4680 CFM @ 0" S.P.)

SKU:BTA18T30075

Weight:76.00

Price: $1,042.23

WTA18T10075 for Moisture Laden Air (18" Dia., 3/4 Hp, 1 Phase, 115V, 4680 CFM @ 0" S.P.)

SKU:WTA18T10075

Weight:76.00

Price: $1,351.88

WTA18T30075 for Moisture Laden Air (18" Dia., 3/4 Hp, 3 Phase, 208-230/460V, 4680 CFM @ 0" S.P.)

SKU:WTA18T30075

Weight:76.00

Price: $1,272.69

BTA18T10100 (18" Dia., 1 Hp, 1 Phase, 115V, 5040 CFM @ 0" S.P.)

SKU:BTA18T10100

Weight:76.00

Price: $1,150.38

BTA18T30100 (18" Dia., 1 Hp, 3 Phase, 208-230/460V, 5040 CFM @ 0" S.P.)

SKU:BTA18T30100

Weight:76.00

Price: $1,064.76

WTA18T10100 for Moisture Laden Air (18" Dia., 1 Hp, 1 Phase, 115V, 5040 CFM @ 0" S.P.)

SKU:WTA18T10100

Weight:76.00

Price: $1,381.49

WTA18T30100 for Moisture Laden Air (18" Dia., 1 Hp, 3 Phase, 208-230/460V, 5040 CFM @ 0" S.P.)

SKU:WTA18T30100

Weight:76.00

Price: $1,295.23

BTA18T10150 (18" Dia., 1.5 Hp, 1 Phase, 115V, 5920 CFM @ 0" S.P.)

SKU:BTA18T10150

Weight:76.00

Price: $1,249.52

BTA18T30150 (18" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 5920 CFM @ 0" S.P.)

SKU:BTA18T30150

Weight:76.00

Price: $1,146.52

WTA18T10150 for Moisture Laden Air (18" Dia., 1.5 Hp, 1 Phase, 115V, 5920 CFM @ 0" S.P.)

SKU:WTA18T10150

Weight:76.00

Price: $1,480.63

WTA18T30150 for Moisture Laden Air (18" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 5920 CFM @ 0" S.P.)

SKU:WTA18T30150

Weight:76.00

Price: $1,376.98

BTA18T10200 (18" Dia., 2 Hp, 1 Phase, 115V, 6590 CFM @ 0" S.P.)

SKU:BTA18T10200

Weight:76.00

Price: $1,375.69

BTA18T30200 (18" Dia., 2 Hp, 3 Phase, 208-230/460V, 6590 CFM @ 0" S.P.)

SKU:BTA18T30200

Weight:76.00

Price: $1,261.75

WTA18T10200 for Moisture Laden Air (18" Dia., 2 Hp, 1 Phase, 115V, 6590 CFM @ 0" S.P.)

SKU:WTA18T10200

Weight:76.00

Price: $1,606.16

WTA18T30200 for Moisture Laden Air (18" Dia., 2 Hp, 3 Phase, 208-230/460V, 6590 CFM @ 0" S.P.)

SKU:WTA18T30200

Weight:76.00

Price: $1,492.21

BTA24T10075 (24" Dia., .8 Hp, 1 Phase, 115V, 6750 CFM @ 0" S.P.)

SKU:BTA24T10075

Weight:132.00

Price: $1,340.29

BTA24T30075 (24" Dia., .8 Hp, 3 Phase, 208-230/460V, 6750 CFM @ 0" S.P.)

SKU:BTA24T30075

Weight:132.00

Price: $1,261.75

WTA24T10075 for Moisture Laden Air (24" Dia., .8 Hp, 1 Phase, 115V, 6750 CFM @ 0" S.P.)

SKU:WTA24T10075

Weight:132.00

Price: $1,641.56

WTA24T30075 for Moisture Laden Air (24" Dia., .8 Hp, 3 Phase, 208-230/460V, 6750 CFM @ 0" S.P.)

SKU:WTA24T30075

Weight:132.00

Price: $1,563.03

BTA24T10100 (24" Dia., 1 Hp, 1 Phase, 115V, 7400 CFM @ 0" S.P.)

SKU:BTA24T10100

Weight:132.00

Price: $1,371.19

BTA24T30100 (30" Dia., 1 Hp, 3 Phase, 208-230/460V, 7400 CFM @ 0" S.P.)

SKU:BTA24T30100

Weight:132.00

Price: $1,284.28

WTA24T10100 for Moisture Laden Air (24" Dia., 1 Hp, 1 Phase, 115V, 7400 CFM @ 0" S.P.)

SKU:WTA24T10100

Weight:132.00

Price: $1,673.75

WTA24T30100 for Moisture Laden Air (24" Dia., 1 Hp, 3 Phase, 208-230/460V, 7020 CFM @ 0" S.P.)

SKU:WTA24T30100

Weight:132.00

Price: $1,584.91

BTA24T10150 (24" Dia., 1.5 Hp, 1 Phase, 115V, 8430 CFM @ 0" S.P.)

SKU:BTA24T10150

Weight:132.00

Price: $1,444.58

BTA24T30150 (24" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 8430 CFM @ 0" S.P.)

SKU:BTA24T30150

Weight:132.00

Price: $1,339.00

WTA24T10150 for Moisture Laden Air (24" Dia., 1.5 Hp, 1 Phase, 115V, 8430 CFM @ 0" S.P.)

SKU:WTA24T10150

Weight:132.00

Price: $1,745.21

WTA24T30150 for Moisture Laden Air (24" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 8430 CFM @ 0" S.P.)

SKU:WTA24T30150

Weight:132.00

Price: $1,639.63

BTA24T10200 (24" Dia., 2 Hp, 1 Phase, 115V, 9260 CFM @ 0" S.P.)

SKU:BTA24T10200

Weight:132.00

Price: $1,611.95

BTA24T30200 (24" Dia., 2 Hp, 3 Phase, 208-230/460V, 9260 CFM @ 0" S.P.)

SKU:BTA24T30200

Weight:132.00

Price: $1,499.29

WTA24T10200 for Moisture Laden Air (24" Dia., 2 Hp, 1 Phase, 115V, 9260 CFM @ 0" S.P.)

SKU:WTA24T10200

Weight:132.00

Price: $1,913.23

WTA24T30200 for Moisture Laden Air (24" Dia., 2 Hp, 3 Phase, 208-230/460V, 9260 CFM @ 0" S.P.)

SKU:WTA24T30200

Weight:132.00

Price: $1,799.93

BTA24T10300 (24" Dia., 3 Hp, 1 Phase, 115V, 10800 CFM @ 0" S.P.)

SKU:BTA24T10300

Weight:132.00

Price: $1,815.38

BTA24T30300 (24" Dia., 3 Hp, 3 Phase, 208-230/460V, 10800 CFM @ 0" S.P.)

SKU:BTA24T30300

Weight:132.00

Price: $1,581.05

WTA24T10300 for Moisture Laden Air (24" Dia., 3 Hp, 1 Phase, 115V, 10800 CFM @ 0" S.P.)

SKU:WTA24T10300

Weight:132.00

Price: $2,117.29

WTA24T30300 for Moisture Laden Air (24" Dia., 3 Hp, 3 Phase, 208-230/460V, 10800 CFM @ 0" S.P.)

SKU:WTA24T30300

Weight:132.00

Price: $1,881.68

BTA30T10100 (30" Dia., 1 Hp, 1 Phase, 115V, 10800 CFM @ 0" S.P.)

SKU:BTA30T10100

Weight:174.00

Price: $1,660.88

BTA30T30100 (30" Dia., 1 Hp, 3 Phase, 208-230/460V, 10800 CFM @ 0" S.P.)

SKU:BTA30T30100

Weight:174.00

Price: $1,573.97

WTA30T10100 for Moisture Laden Air (30" Dia., 1 Hp, 1 Phase, 115V, 10800 CFM @ 0" S.P.)

SKU:WTA30T10100

Weight:174.00

Price: $2,121.16

WTA30T30100 for Moisture Laden Air (30" Dia., 1 Hp, 3 Phase, 208-230/460V, 10800 CFM @ 0" S.P.)

SKU:WTA30T30100

Weight:174.00

Price: $2,033.61

BTA30T10150 (30" Dia., 1.5 Hp, 1 Phase, 115V, 12320 CFM @ 0" S.P.)

SKU:BTA30T10150

Weight:174.00

Price: $1,758.08

BTA30T30150 (30" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 12320 CFM @ 0" S.P.)

SKU:BTA30T30150

Weight:174.00

Price: $1,652.51

WTA30T10150 for Moisture Laden Air (30" Dia., 1.5 Hp, 1 Phase, 115V, 12320 CFM @ 0" S.P.)

SKU:WTA30T10150

Weight:174.00

Price: $2,218.36

WTA30T30150 for Moisture Laden Air (30" Dia., 1.5 Hp, 3 Phase, 208-230/460V, 12320 CFM @ 0" S.P.)

SKU:WTA30T30150

Weight:174.00

Price: $2,113.43

BTA30T10200 (30" Dia., 2 Hp, 1 Phase, 115V, 13810 CFM @ 0" S.P.)

SKU:BTA30T10200

Weight:174.00

Price: $1,873.96

BTA30T30200 (30" Dia., 2 Hp, 3 Phase, 208-230/460V, 13810 CFM @ 0" S.P.)

SKU:BTA30T30200

Weight:174.00

Price: $1,760.66

WTA30T10200 for Moisture Laden Air (30" Dia., 2 Hp, 1 Phase, 115V, 13810 CFM @ 0" S.P.)

SKU:WTA30T10200

Weight:174.00

Price: $2,334.88

WTA30T30200 for Moisture Laden Air (30" Dia., 2 Hp, 3 Phase, 208-230/460V, 13810 CFM @ 0" S.P.)

SKU:WTA30T30200

Weight:174.00

Price: $2,221.58

BTA30T10300 (30" Dia., 3 Hp, 1 Phase, 115V, 15490 CFM @ 0" S.P.)

SKU:BTA30T10300

Weight:174.00

Price: $2,057.43

BTA30T30300 (30" Dia., 3 Hp, 3 Phase, 208-230/460V, 15490 CFM @ 0" S.P.)

SKU:BTA30T30300

Weight:174.00

Price: $1,821.81

WTA30T10300 for Moisture Laden Air (30" Dia., 3 Hp, 1 Phase, 115V, 15490 CFM @ 0" S.P.)

SKU:WTA30T10300

Weight:174.00

Price: $2,517.71

WTA30T30300 for Moisture Laden Air (30" Dia., 3 Hp, 3 Phase, 208-230/460V, 15490 CFM @ 0" S.P.)

SKU:WTA30T30300

Weight:174.00

Price: $2,282.74

BTA30T10500 (30" Dia., 5 Hp, 1 Phase, 115V, 18410 CFM @ 0" S.P.)

SKU:BTA30T10500

Weight:174.00

Price: $2,231.24

BTA30T30500 (30" Dia., 5 Hp, 3 Phase, 208-230/460V, 18410 CFM @ 0" S.P.)

SKU:BTA30T30500

Weight:174.00

Price: $1,894.56

WTA30T10500 for Moisture Laden Air (30" Dia., 5 Hp, 1 Phase, 115V, 18410 CFM @ 0" S.P.)

SKU:WTA30T10500

Weight:174.00

Price: $2,692.16

WTA30T30500 for Moisture Laden Air (30" Dia., 5 Hp, 3 Phase, 208-230/460V, 18410 CFM @ 0" S.P.)

SKU:WTA30T30500

Weight:174.00

Price: $2,354.84


Tube Axial Duct Fan 4" Support Legs	Tube Axial Companion Ring	Tube Axial Duct Fan Guard	Tube Axial Inspection Door
Tube Axial Vertical and Horizontal Support Clips	Tube Axial Duct Fan Galvanized Motor & Belt Cover
