Exhaust Fans → Industrial Exhaust Fans → Canarm Ltd. brand Model ALX-DB Down Blast Belt Drive Spun Aluminum Centrifugal Roof or Wall Exhaust Fan Single or Three Phase Gen. Application CFM Range: 1,303-7,188
Canarm Ltd. brand Model ALX-DB Down Blast Belt Drive Spun Aluminum Centrifugal Roof or Wall Exhaust Fan Single or Three Phase Gen. Application CFM Range: 1,303-7,188
Price:
$993.26
Price:
$986.33
Price:
$1,057.91
Price:
$950.40
Price:
$1,048.51
Price:
$1,064.55
Price:
$922.53
Price:
$1,223.21
Price:
$1,269.49
Price:
$1,248.98
Price:
$1,049.90
Price:
$1,228.50
Price:
$1,174.93
Price:
$1,274.13
Price:
$1,222.07
Price:
$1,403.31
Price:
$1,236.62
Price:
$1,493.45
Price:
$1,275.19
Price:
$1,521.89
Price:
$1,465.19
Price:
$1,598.59
Price:
$1,598.01
ALX-DB Series - Downblast Belt Drive Spun Aluminum Roof Exhauster
Ideal for exhausting air from factories, offices, warehouses or commercial buildings. The ALX series spun aluminum exhaust fan can be used as either a roof top or wall mount exhaust fan.
FEATURES
- Spun aluminum housing will not rust, chip or peel.
- Aluminum backward inclined wheel is non-overloading.
- Belt Drive.
- Available with a variety of field or factory installed 1 phase & 3 phase motors.
- Units up to 24" (max 2 HP) can be wall mounted.
- Quick release latches for easy motor access.
- Standard bird screen.
- Sizes up to 165 can be wall mounted. Wall Mount bracket req'd.
TYPICAL MAXIMUM CFM @ STATIC PRESSURE |
|||||
1 Ph Model |
3 Ph Model |
HP |
0”SP |
1/8”SP |
1/4”SP |
ALX130DBT10025 |
|
1/4 |
1303 |
1236 |
1162 |
ALX135DBT10033 |
|
1/3 |
1498 |
1443 |
1383 |
ALX135DBT10050 |
|
1/2 |
1722 |
1674 |
1623 |
ALX150DBT10050 |
|
3/4 |
1856 |
1784 |
1708 |
ALX150DBT10075 |
|
1 |
2196 |
2132 |
2072 |
ALX150DBT10100 |
ALX150DBT30100 |
1 |
2376 |
2320 |
2264 |
ALX165DBT10100 |
ALX165DBT30100 |
1 |
2600 |
2611 |
2509 |
ALX165DBT10150 |
ALX165DBT30150 |
1 ½ |
3100 |
3076 |
2993 |
ALX180DBT10100 |
ALX180DBT30100 |
1 |
3682 |
3583 |
3419 |
ALX180DBT10200 |
ALX180DBT30200 |
2 |
4089 |
4002 |
3878 |
ALX210DBT10150 |
ALX210DBT30150 |
1 ½ |
4860 |
4746 |
4551 |
ALX245DBT10150 |
ALX245DBT30150 |
1 ½ |
5910 |
5668 |
5415 |
ALX245DBT10200 |
ALX245DBT30200 |
3 |
6428 |
6210 |
5979 |
ALX245DBT10300 |
ALX245DBT30300 |
3 |
7188 |
6992 |
6797 |
